Computer Aided Drafting (CAD)

Accurate models that keep legacy systems alive
Audit Ready CAD Workflows

CAD Support at High Bridge Solutions

For High Bridge Solutions, CAD isn’t just “drawing pretty parts.” It’s how we turn worn, undocumented, or obsolete hardware into fully defined, production-ready models and drawings that your programs can trust.

In the context of HBS, CAD / Computer-Aided Drafting is the bridge between:

  • A physical sample or partial print

  • And a complete, controlled technical data package (TDP) that supports reverse engineering, assembly, test, and long-term sustainment.

We support primes, OEMs, and government customers who need legacy components digitized, updated to modern standards, and ready for manufacturing.

Engineering workstation with CAD drawing and parts
Defense-grade CAD for legacy systems

Why Teams Choose High Bridge Solutions for CAD

Legacy Experts

We specialize in taking old, under-documented parts and turning them into modern, producible designs that keep legacy hardware in service.

Obsolescence Solutions

Our CAD work is built around DMSMS and obsolescence programs, helping you replace hard-to-source parts with fully documented, production-ready equivalents.

Integrated Supply

Because CAD is done inside a supply chain integrator, our models and drawings reflect real-world sourcing, manufacturability, and cost realities.

Defense Mindset

Our team understands the documentation, traceability, and configuration control expectations of defense and aerospace customers.

Flexible Scaling

Whether you need a single legacy part documented or an entire family of components standardized, our process scales with your program.

Audit Ready

Computer-aided drafting files, drawings, and associated records are organized so they can stand up to technical data, quality, or program reviews.

Quality and compliance behind every drawing

Certified to Support Your CAD Work

ISO 9001:2015

Our CAD and drafting activities are governed by an ISO 9001:2015-certified quality system, so models and drawings follow controlled processes, documented reviews, and traceable revisions.

Every process measured, managed, and verified for quality.

CAGE Code 71RR2

As a registered small business with CAGE 71RR2, HBS is already set up to support U.S. Government and prime contractor programs, simplifying onboarding and contracting for CAD and technical data work.

Audit-ready cybersecurity built to protect CUI.

CMMC Level 2 (Aligned)

High Bridge Solutions is aligning its cybersecurity controls with NIST SP 800-171 Rev 3 in preparation for CMMC Level 2 assessment. Our infrastructure, policies, and personnel training are structured to safeguard sensitive program data.

Demonstrates readiness for secure collaboration.

JCP Certified (DD 2345)

HBS is approved under the Joint Certification Program, authorizing access to unclassified technical data governed by DoD and DoC export control regulations. This certification allows collaboration with customers who require controlled design packages, drawings, and documentation.

Allows HBS to receive controlled technical data immediately.

Spacious empty warehouse with polished concrete floor
From physical part to controlled TDP

Typical CAD Engagements

You’ll typically bring HBS in when you need to:

  • Reverse engineer and document an obsolete or hard-to-source part

  • Convert legacy drawings into modern, clean CAD models and prints

  • Create new drawings and views to support assembly, installation, or maintenance

  • Standardize a family of parts under a single, controlled drawing and revision scheme

  • Support new suppliers with clean, unambiguous data packages that reduce RFIs and build errors

Answers To Your Questions

Our FAQ for CAD & Computer-Aided Drafting

A complete sample part is ideal, but we can often work from partial parts, legacy drawings, or a mix of both and identify any remaining unknowns during the process.
Absolutely. We can model the current configuration, then work with your team to incorporate design improvements, tolerance adjustments, or material changes.
CAD is the foundation for our engineering support, reverse engineering, assembly and test, and supply chain work. One clean data set that feeds everything else.
Next Step

Mission-Ready Starts Here.

Let’s connect and build the supply advantage your program demands.

Engage Now →
